Tektronix Oscilloscope
Pricing
$25 / hour
Faculty of Medicine and Dentistry
Physical Medicine and Rehabilitation
University of Alberta
Overview: The Tektronix 4 Series MSO is a digital oscilloscope designed for waveform analysis, signal integrity testing, and debugging in engineering electronics. It offers high bandwidth and sampling rate capabilities to capture transient signals effectively.
Key Features:
- Innovative pinch-swipe-zoom touchscreen interface
- High-definition display
- 4 or 6 FlexChannel® inputs
- Upgradable bandwidth options
- Advanced analysis tools
Technical Specifications:
- capacity: 31.25 Mpoints standard (62.5 Mpoints optional upgrade)
- accuracy: 12-bit ADC resolution
- precision: Up to 16-bits in High Res mode
- range: Bandwidth from 200 MHz to 1.5 GHz (upgradable)
- speed: Real-time sample rate of 6.25 GS/s
- power: Auxiliary Trigger ≤300 VRMS
- dimensions: Not specified
Applications: Ideal for research and development in electronics, signal integrity testing, and debugging complex embedded systems.
